Boreal Pinion
***Sold out. Subscribe to our newsletter to be informed of the next availability.
After conclusive tests on the 2500+km Baja Divide in Mexico and during the TransBoreale expedition (complete winter crossing of Quebec from south to north), the Boreal Pinion bike is offered in a limited series. Each bike will be painted to order, making it completely unique.
The Boreal Pinion is designed to carry its rider with confidence on journeys and expeditions around the world. The frame and fork are robust, and the components are extremely reliable and low-maintenance.
The highlight of the Boreal Pinion is the Pinion drivetrain. Combined with the Gates carbon belt, it is virtually maintenance-free and extremely durable. The performance of the Pinion internal gear system is unsurpassed, while the wide range of gear ratios is exceedingly large (600% for the C1.12 model – other models available on request) and each gear is evenly spaced.
For half-road/half-off-road touring, 29×2.0 (700×50 equivalent) tires will provide an optimum ride. For off-road use, 27.5″ tires of equivalent diameter, i.e. 27.5×2.6, are the appropriate choice. The two 32-spoke wheel options (for greater durability) are offered with the purchase of the complete bike. In both options, no lack of mud clearance while the frame and fork can accommodate 29×2.8 tires.
*The frame/fork+Pinion set comes complete with Pinion C1.12 drivetrain, forged aluminum crank arms and shifter. Wheel axles, installed headset, seatpost collar and frame protectors are also included.
Pickup currently unavailable at Panorama Cycles
Sizing guide - boreal pinion
Riding with a well-fitted bike is key to comfort, performance and fun! Contact us for any technical questions you may have. Complete geometry chart can be found on this page.
| SMALL | MEDIUM | LARGE | |
|---|---|---|---|
| APPROXIMATIVE CYCLIST HEIGHT | 5’4’’ – 5’8’’ | 5’8’’ – 5’11’’ | 5’11’’ – 6’3’’ |
Product information
We are proud to offer products on which all the details have been reflected and validated.
The warranty offered on Panorama bicycles covers the owner for 5 years against any manufacturing defects. Return the bike after 10 days of testing if anything is not up to your expectations. Your satisfaction (and especially your fun outdoor) is at the top of our priorities. See the Terms of Sale for more information.
Head over here if you want to learn more about the values and vision behind Panorama Cycles products.
We know you want your order as soon as possible! We will ship your box once the order is confirmed, and be sure the product you ordered will be carefully wrapped to protect it during shipment.
We use flat rates for all of Canada and the United States. This rate will be displayed at the time of payment for your purchase. Custom duties are included in the purchase price for US shipment.
For international purchases, please contact us prior to placing your order so that we can send you the best possible shipping rate. The prices varies quite a lot depending of the region. for complete bike, the cheapest way to ship the bike in parts (not assembled) in 2 boxes.
As an example, here are some ball-park rates for shipping to Europe (again please contact to validate the exact rate to the final destination):
Frameset: 200-350$CAD
Complete bike in parts: 450-700$CAD
Complete bike assembled: 700-950$CAD
Visit or contact one of our key partner in order to know if they currently have in stock the model and size that you are looking for.
Panorama Boreal Pinion
ALL TERRAIN TOURING GEOMETRY
The combined 68deg head angle and 470-485mm chainstays give the Boreal a large wheelbase that inspires confidence when the bike is loaded.
Steering remains precise for navigating difficult terrain at low/medium speed, thanks to the 62mm fork offset (mechanical trail of 79mm).
Main Features
REYNOLDS 525 TUBESET
Custom selection of Reynolds 525 steel tubes used with reinforcements. Extremely robust and durable, perfectly suited to a heavily loaded bike.
PINION TRANSMISSION
The Pinion drivetrain offers an extremely robust system requiring little maintenance or lubrication compared to a derailleur drivetrain. The speed range is 600% (vs. 510% for a Shimano mountain transmission) and gears are evenly spaced.
WHEELSET/TIRES COMPATIBILITY
Ready for anything with maximized mud clearance (29×2.8).
Choose fast 29×2” (700×50 equivalent) tires for more rolling roads, or go for wide tires with an equivalent 27.5″ diameter, i.e. 27.5×2.6″. The latter is ideal for off-road adventures.
MULTIPLE MOUNTING POINTS
Triple mounts on the downtube, double mounts on the seat tube, top tube bag, cargo cage mounts on the fork, front and rear luggage rack and mudguards.
INTERNAL CABLE ROUTING FOR DYNAMO
The fork is designed for use with a dynamo hub. There’s also a mount on the front of the fork for attaching a light.
Panorama boreal pinion
CUSTOMIZED PAINT
Option 1: Custom powder coating
Extremely durable coating for your bike. Single color for frame and fork. High-gloss finish. Choose your color by following the link below. (A validation sample can be ordered on request)
Option 2: Custom liquid paint
Want a funky, unique design, gradients, multiple colors? Contact us by e-mail. Minimum additional charge of $800CAD.
Specifications
All our bikes are assembled at our factory in Granby, Canada, so we offer some customization options.
Weight of the frameset and Pinion gearbox: +/- 17lbs.
Weight of complete bike: approx. +/- 34lbs
You want to customize your bike by replacing a few parts? Send us your wish list and we will be pleased to answer your request.
Frame
INTERNAL CABLE ROUTING DROPPER SEATPOST
ADJUSTABLE REAR WHEEL DROPOUT
BELT DRIVE COMPATIBLE
POST-MOUNT BRAKE STD
MOUNTS FOR LUGGAGE RACK AND MUDGUARD
TRIPLE WATER BOTTLE MOUNT UNDER AND ON TOP OF THE DOWNTUBE
WATER BOTTLE MOUNT ON SEAT TUBE
GAS TANK BAG MOUNT ON TOP TUBE
12MMX148MM BOOST REAR AXLE
STEERING TUBE 1-1/8¨
HEADSET: TOP EC34 LOWER EC34
SEATPOST COLLAR DIA 29.8MM
SEATPOST DIA 27.2MM
MAX TIRE CLEARANCE: 29¨X2.8¨, 27.5¨X3¨
Fork
CUSTOM CR-MO 4130
POST MOUNT BRAKE STD
RACK MOUNTS
MUDGUARD MOUNTS
TRIPLE CARGO CAGE MOUNT
DYNAMO HUB COMPATIBLE
15MMX110MM AXLE
1-1/8¨ HEAD TUBE
MAX TIRE CLEARANCE: 29X2.8¨, 27.5¨X3¨
Components
| Wheels |
OPTION W1-1: WTB STi30 27.5¨ / SHIMANO TC500 (FRONT) / TC600 (REAR), 32 HOLES, CENTERLOCK, HG OPTION W1-2: INDUSTRY NINE BACKCOUNTRY 360 27.5¨ / HYDRA HUBS / 6 BOLTS, 32 HOLES, HG OPTION W2-1: WTB STi23 29¨ / SHIMANO TC500 (FRONT) / TC600 (REAR), 32 HOLES, CENTERLOCK, HG OPTION W2-2: VELOCITY CLIFFHANGER 29¨ RIMS / INDUSTRY NINE HYDRA HUBS / 6 BOLTS, 32 HOLES, HG |
| Tires | OPTION W1: MAXXIS REKON, 27.5X2.6, EXO/TR, 60TPI, BLACK
OPTION W2: SCHWALBE MARATHON MONDIAL, 29X2.0¨ (700X50), DOUBLE DEFENSE, V GUARD |
| Drivetrain | PINION C1.12 (other models available on special request) |
| Crank arms | PINION, FORGED ALUMINUM, 165,170,175MM |
| Rear Sprocket | GATES CDX 39T STAINLESS |
| Front Sprocket | GATES CDX 39T STAINLESS |
| Belt | GATES CDX |
| Shifter | PINION DS2.12 |
| Brakes | OPTION 1: SRAM LEVEL OPTION 2: SRAM LEVEL T OPTION 3: SHIMANO XT 4 PISTONS M8120 |
| Rotors | SRAM CENTERLINE, 180MM FRONT, 160MM REAR, CENTERLOCK OU SHIMANO RT-70 |
| Handlebars | VELO ORANGE CRAZY BARS |
| Stem | PROMAX FA-283, 60MM, 7DEG |
| Headset | FSA ORBIT EQUIPE NO.21 |
| Seatpost | KALLOY SP-3D2, 27.2mm X400mm |
| Saddle | WTB VOLT |
| Pedals/Racks | Not included |
Warranty
5 years – Read all details in our User Manual
User Manuals
Geometry
Who this bike is for:
- Expeditions/long-distance bike trips appeal to you.
- You want a bike that’s comfortable, ready for any type of terrain, and offers outstanding reliability/durability.
Not exactly what you are looking for?
Interested in this bike but would prefer a classic drivetrain or a Rohloff hub?Take a look at the Boreal.
Riding with a well-fitted bike is key to comfort, performance and fun! Contact us for any technical questions you may have.
geometry chart
| SMALL | MEDIUM | LARGE | |
|---|---|---|---|
| APPROXIMATIVE CYCLIST HEIGHT | 5’4’’ – 5’8’’ | 5’8’’ – 5’11’’ | 5’11’’ – 6’3’’ |
| STANDOVER HEIGHT | 730mm | 750mm | 780mm |
| HEAD TUBE ANGLE | 68° | 68° | 68° |
| SEAT TUBE ANGLE | 73.5° | 73.5° | 73.5° |
| STACK | 602mm | 621mm | 639mm |
| REACH | 416mm | 425mm | 445mm |
| HEAD TUBE LENGTH | 150mm | 170mm | 190mm |
| SEAT TUBE LENGTH | 440mm | 460mm | 490mm |
| HORIZONTAL TOP TUBE LENGTH | 597mm | 611mm | 637mm |
| CHAINSTAY LENGTH | 470-485mm | 470-485mm | 470-485mm |
| BB DROP | 65mm | 65mm | 65mm |
| FORK RAKE/OFFSET | 62mm | 62mm | 62mm |
| WHEELBASE | 1165mm | 1178mm | 1210mm |
| TRAIL | 79mm | 79mm | 79mm |
| STEM LENGTH | 60mm | 60mm | 60mm |
